SHAPING STEEL SOLUTIONS
LONIA · REAR HINGES 270º
PALA TRASERA LONIA 3 TALADROS
REAR HINGE BLADE LONIA 3 FIXING HOLES
205010267 205010167 ø26,5 ø10,3
INOX ZINC
35,0 3,0
637 g. 634 g.
7,0
124,8 15,2
277,0
80,0 62,0 31,0
3x ø8,5
70,0 64,0
150,0
263,0
290,0
SOPORTE ESCUADRA 25
SQUARE BRACKET 25
200000205 200000106 71,5
ø 10,2
INOX ZINC
338 g. 174 g. 43,5 3,0 31,0
ø
31,0 2x 6.8 15,5
10 88°
86,0
135,0
2x 6.8
ø
9,0
116,0
153
