SHAPING STEEL SOLUTIONS
SIDE HINGES 180º · FLAT
BISAGRA LATERAL NAVIA CON GALCE
SIDE HINGE NAVIA WITH SLOPE
401240209
INOX
1.066 g.
15,5 19,5
57,3
247,9
3x 6,5 3x ø 6,5
ø
68,1 27,5
30,5 30,5
120,0 120,0
30,5 30,5
121,0 138,0
277,0
BISAGRA LATERAL PLANA DEZA
FLAT SIDE HINGE DEZA
418100201 418100101
INOX ZINC
ø 18,3
638 g. 623 g. 21,2 12,0
4,0
58,0 165,0
3x ø 8,5
3x ø 8,5
10,0
43,0
110,4 49,0 68,0
43,0
10,0
11,0 21,0 26,0 55,5 98,5
223,0
